Installation Made Easy

The PoE technology can transmit both data and power via only one Ethernet cable, streamlining setup.

24/7 Recording

Continuous recordings directly to your hard drive with expandable storage.

32 Channels, Up to 48MP

Supports up to 32 channels of IPC access; each channel up to 48MP input without any monthly costs.

Stay Connected via Your Phone/PC

Know what's happening on your property anytime, anywhere via your Reolink App and Client, whether you're at home or on the go. No monthly fees.

Find the Clip Needed Quickly

Effortlessly navigate through your video footage with time and event filters to quickly find the exact clip you need, saving you time and hassle.

Specifications

Hardware

Video/Audio Input

Video Input
Supports up to 36 channels of IPC access; each channel up to 12MP input

Video/Audio Output

• Via bulit-in 1 channel

Decoding

Live View / Playback Resolution
4608x1728, 4512x2512, 4096x3072, 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p
(supports only 1-channel playback if you view it in 8MP or higher resolution.)

Synchronous Playback
Up to 4 channels

HDD

SATA
3 SATA ports for 3 HDDs (optional)

External HDD
No

Capacity
48TB (max. 16TB HDD for each SATA)

Network

Network Protocol
HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP

OS Supported
PC: Windows, Mac OS; smartphone: iOS, Android

Browser Supported
Firefox, Chrome, Edge, Safari

Max. User Access
20 users (1 admin account & 19 user accounts); up to 12 simultaneous video streams (10 substreams & 2 mainstreams)

General

Power Supply
DC 12V/5.4A

Working Environment
Temperature: -10°C~+45°C (14°F~113°F); humidity: 10%~90%

Weight
2.26kg

Power Consumption
<10W (without HDD & PoE)

Dimensions
330 x 48 x 310mm
